Solar Panel 260W Perlight Poly...
Solar Panel Perlight Poly PV Module 260W
PLM-250P-60
Tolerance ± 0-3%. Voc 37.92V
Isc 8.64A,
Vmp 32.10V
Imp 8.10A
No.of cells 60/156x156mm polycrystalline, 1640*992*40mm, low-iron tempered glass / 3.2mm. Temperature Coefficient:
NOCT 45°C±2°C.
Temperature coefficient of Isc 0.05%/°C.
Temperature coefficient of Voc -0.33%/°C.
Temperature coefficient of Pmax -0.44%/°C.
Power Tolerance 0/+3%.
Working temperature -40°C to 85°C.
Qualification Test Parameters:
Temperature cycling range -40~85.
Humidity freeze, damp heat 85%RH.
Static load front and back (e.g. wind) 2400 pa (50psf).
Front loading (e.g. snow) 5400 pa (113psf).
Hailstone impact 25mm ( 1 inch) at 23 m/s (52mph). Weight(KG) 19.6,
No.of mounting holes 8,
No.of waterspout 16. Power warranty:
20 years
Гаранција: 120 месеци
|
